K&M LOUDSPEAKER AND LIGHTING STANDS - Accessories

21406

Packaged in pairs, these cable clamps are suitable for speaker or lighting stands with diameters of 35-42mm. The 'wear-resistant' plastic clamp allows for neat placement of cables for safety and aesthetic uses.

21320

Available in two sizes, 21320 safety ring is designed to be slid over the extension tube of a speaker or lighting stand, and lock in place to prevent stand slippage. Both variants are manufactured from 'impact-resistant' plastic and are black in colour.

Options

24116

This connector plate is designed to be mounted in a subwoofer as inverted 'top-hat'. It is compatible with distance rods terminating with M20 bolt. Weight: 0.24kg

19654

'Internal', plastic, 'top-hat' flange-adapter for the bottom of loudspeakers, secured via four 6.5mm mounting holes on flange plate. Slips onto all stands with a 35mm spigot. Flange plate diameter 105mm with a depth of 60.5mm. Weight: 0.077kg.

19656

'Internal', zinc, die-cast, 'top-hat' flange-adapter for the bottom of loudspeakers, secured via four 6.5mm mounting holes on flange plate. Slips onto all stands with a 35mm spigot. Flange plate diameter 105mm with a depth of 75mm. Weight: 0.34kg.

19665

'Internal', plastic coated, steel, 'top-hat' flange-adapter for the bottom of loudspeakers, secured via four 6.5mm mounting holes on flange plate. Slips onto all stands with a 25mm spigot. Flange plate diameter 105mm with a depth of 78mm. Weight: 0.38kg.

24521

Available in four sizes, 24521 reducing flange adapters are designed to convert a 35mm diameter speaker pole to fit differing thread types or diameters. All models feature large hand knob for tightening.

Options

24528

A reducer flange similar to 24521-000-55 however the M10 connection is female. Length: 100mm. Weight: 0.46kg

21326

Polyamide adapter sleeve for speaker flanges with an inside diameter of 38mm, suited to stands with spigots of 35mm diameter. Length: 102mm. Weight: 0.01kg.

21324 Adapter Bolt - M20 to 35mm

Manufactured in aluminium, 21324 adapter flange is designed to convert a distance rod with M20 thread into a base diameter of 35mm to fit compatible sub bass speakers.

24105

Stand adapter for the mounting of two speakers which are fitted with flange adapters. Suited to stands with spigots of 35mm diameter, secured by locking screw. Two speaker spigots 35mm diameter x 120mm are fixed to a T-bar with adjustable width of 310 - 490mm. Maximum load: 2x 25kg, Weight: 1.48kg.

19674

Speaker tilt adapter, fits and locks onto all stands with 35mm spigot. Provides a secondary 35mm spigot with angle adjustment from 0 degrees vertical to 15 degrees tilt, secured by a locking screw. Locks into speakers via expanding mandrel system controlled by easy-to-use ring-lock. Height 230mm, maximum load capacity 25kg, weight 0.85 kg.

19670

Speaker tilt adapter, fits and locks onto all stands with 35mm spigot. Provides a secondary 35mm spigot with angle adjustment from 0 degrees vertical to 15 degrees tilt, secured by a locking screw. Height: 300mm. Maximum load capacity: 25kg. Weight: 0.67kg.

19780

Stand adapter with tilt, for mounting equipment without the need for an incorporated flange. Suited to stands with a spigot diameter of 35mm, locking in position via clamping screw. Tilt adjustment of 30 degrees. two 10.5mm fixing holes with a fixing range of 70 - 76.2mm. Maximum load capacity: 15kg. Weight: 0.547kg.

195/8

'External' flange for mounting onto the bottom of equipment. Locking-screw to tighten onto top of stand. Suits all stands with 35mm spigot. Flange plate dimensions 175 × 110mm, height 140mm. Two slots 9.5x35mm, fixing centres range 100-152mm. Weight: 0.68kg.

24281

'External' flange for mounting onto the bottom of speakers. Locking screw to tighten onto top of stand. Suits all stands with 35mm spigot. Flange plate dimensions 146x40mm, height 105mm. Two 11mm mounting holes with fixing centres of 115mm. Weight: 0.56kg.

26706

A solid base plate with M20 threaded bolts in three positions. A cable through port allows for discreet cabling, whilst a carry handle allows for ergonomic transportation. Available in black or white finish. Dimensions (WxDxH): 550 x 550 x 27.3mm.

26711 Base Plate S, single mounting position

Weighing 7.4kg, 26711 is a heavy and solid base plate for all standard distance rods and rod combinations with M20 threaded bolts. The base plate has a cable management port and four rubber feet for stability. When not in use an ergonomic carrying handle allows for easy transport. Dimensions: 406 x 406mm. Weight: 7.4 kg.

26707 Base Plate S, 3x M20 mounting positions

This heavy base plate is suitable for all standard distance rods and rod combinations with M20 threaded bolts. The base plate allows three ways to position the optional column with a centric, off-center position, and corner mounting. The ergonomic carrying handle allows for easy transportation, whilst a cable management port and four 'sturdy' rubber feet can be employed during use. Dimensions: 406 x 406mm. Weight: 7.5kg.

26712 Base Plate M, single mounting position

This base plate has the same functionality as 26711 however it is larger in size at 489 x 489mm, and weighs 10.7kg for studier requirements.

26713 Base Plate M, 3x M20 mounting positions

This base plate has the same functionality as 26707 however it is larger in size at 489 x 489mm, and weighs 10.7kg for studier requirements.

26715 Base Plate L, single mounting position

Available in black or white finish, this base plate is the largest in the series measuring 550 x 550mm and weighing 13.5kg. All features as 26711

26716 Base Plate L, 3x M20 mounting positions

Available in black or white finish, this base plate is the largest in the series measuring 550 x 550mm and weighing 13.5kg. All features as 26707.

26709 Weight

An optional steel manufactured weight for base plate and distance rod combinations to give added sturdiness and security. Weight: 5kg.

26792 - Universal Monitor Plate

Support plate for monitor speakers, screws to the top of the K&M 26795 monitor stand. Supplied complete with four rubber feet and four spikes.Supplied complete with four rubber feet and four spikes.

The following are for use with the 24471 and 24481 wall mounts and the 24496 ceiling mount. They consist of a metal plate and two fasteners to attach the plate to the mount. The plates are punched with a variety of mounting holes to suit many popular loudspeakers, including models from Bose, Focal, Genelec, JBL, K+H, Neumann and Tannoy. The terms vertical and horizontal refer to the orientation of the plate when fixed to the mounts, which are assumed to be mounted vertically in each case, to allow the tilt mechanisms to work.

19611 Adapter

Compatible with adapter plates 24352 to 24359, this adapter has been designed for mounting on speaker and light stands with diameter 35 mm extension tube. Also compatible with VESA adapter plates 19615, 19616, 19617 and 19618, the adapter enables the user to convert a speaker stand into a screen stand.

19610 Adapter

A multifunctional stand adapter for mounting on stands with 35mm diameter extension tubes. The adapter can be adjusted to an inclination of +60 to -30 degrees. The fixation follows by means of an adjustable clamping lever. The adapter plates 19615, 19616 and 19617 can be used to mount a wide variety of screens up to a mounting hole pattern of VESA 200x200 mm. The adapter plates 24352 to 24359 are suitable for accommodating a large number of loudspeaker cabinets. Maximum load capacity: 25kg. Weight: 0.88kg.

24352 Adapter panel 1, vertical

'Universal' mounting adapter panel, vertical orientation. The plate has dimensions 95 x 150(h x v)mm with several sets of mounting holes: 4x M8 on 70 x 127(h x v)mm pitch, 4x M6 on 50.8 x 107.9(h x v)mm pitch, 4x M6 on 62 x 47(h x v)mm pitch combined with two slots for M6, 70 to 76.2(h)mm pitch. Weight: 0.33kg. Available in black or white finish.

24354 Adapter panel 2, horizontal

'Universal' mounting adapter panel, horizontal orientation. The plate has dimensions 150 x 95(h x v)mm with several sets of mounting holes: 4x M8 on 127 x 69.9(h x v)mm pitch, 4x M6 on 107.9 x 50.8(h x v)mm pitch, and 2x slots for M6, 70 to 76.2(h)mm pitch. Weight: 0.33kg. Available in black and white finish.

24356 Adapter panel 3, horizontal

Adapter panel, horizontal orientation. Plate dimensions 71 x 128(h x v)mm, with four mounting holes for M6 fasteners on 50.8 x 107.9(h x v)mm pitch. Weight: 0.22kg. Available in black or white finish.

24357 Adapter panel 4, vertical

Adapter panel, vertical orientation. T-shaped plate dimensions 128 x 90(h x )mm overall, with four mounting holes for M6 fasteners, 107.9 x 50.8(h x v)mm pitch. Weight: 0.24kg. Available in black or white finish.

24358 Adapter panel 5, vertical

Adapter panel, vertical orientation. Plate dimensions 40 x 145(h x v)mm with two mounting holes for M10 fasteners, 115(v)mm pitch. Weight: 0.24kg. Available in black or white finish.

24359 Adapter panel 6, horizontal/vertical

Adapter panel, horizontal and vertical orientation. T-shaped plate dimensions 90 x 100(h x v)mm overall with one pair of mounting slots for M6 fasteners on 70 - 76.2(h)mm pitch and one pair of mounting holes for M6 fasteners on 70(v)mm pitch. Weight: 0.14kg. Supplied complete with locking screws for Genelec 8000 Series. Available in black or white finish.

24452

This adapter panel has the same features as 24359 however it has a u-shaped bend to allow space for cable routing. Compatible with Genelec 8020, 8030, 8320, and 8330 loudspeakers, see GENELEC ACTIVE LOUDSPEAKERS - Studio Monitors

21316

Carrying case - For up to two speaker stands. 1680D nylon material with separate internal compartments and padded handles. Case entry via dual zippered panel at the end of the case. Dimensions: 1200mm. Weight: 2.1kg.

21311

Carrying case – For up to two speaker/lighting stands. The waterproof nylon case has two inner compartments, each with zip fastener. Two handles can be tethered with wrap-around grip. Dimensions: 1200 x 250 x 250mm. Weight: 1kg

21422

Carrying case – For up to two monitor/speaker stands. Manufactured from waterproof nylon, access to the two inner compartments is by way of draw-string closure at one end of the bag. Two handles can be tethered with wrap-around grip. Dimensions: 1290 x 140 x 140mm. Weight: 0.36kg

21312

Carrying case – For up to two speaker/lighting stands. The waterproof nylon case has two inner compartments, each with zip fastener. Two handles can be tethered with wrap-around grip. Although the dimensions are the same as that of 21311, 21312 is manufactured from sturdier material and is therefore said to be a more professional case. Dimensions: 1200 x 250 x 250mm. Weight: 1.2kg

24608

A 'sturdy' carrying case made of tear-resistant nylon fabric designed for the transportation of 2x distance rods measuring up to 1115mm in length. The padded case has 2x zippers and carrying handles. Dimensions: 1115 x 220 x 120mm. Weight: 0.77kg

24609

Manufactured of tear-resistant nylon fabric, this case is for 2x distance rods with a length of 1420mm - protecting against dirt and scratches. The padded case has 2x zippers and carrying handles. Dimensions: 1420 x 200 x 140mm. Weight: 0.93kg

24627

24627 carrying case is made from tear-resistant nylon material and designed for the transportation of 26715 or 26716 base plate - protecting against dirt and scratches. A single zipper and cushioned handle provide extra comfort and safety. Dimensions: 560 x 560 x 30mm. Weight: 0.5kg

24616

A carrying case for 26707 or 26711 Base Plate S. The tear-resistant nylon fabric protects the base from dirt and scratches. A single zipper and convenient carrying handles offer additional comfort and safety. Dimensions: 406 x 406 x 30mm. Weight: 0.29kg

24617

A practical carrying case for the 26712 or 26713 Base Plate M. Dimensions: 489 x 489 x 30mm. Weight: 0.39kg
