A selection of JBL Control series, ceiling mounted speakers that can be used as part of music systems within cafes, high street stores, airports, and hotels, as well as being equally at home as paging systems in receptions courtrooms, or waiting rooms.
Discontinued
A 70V/100V/8ohm, full range ceiling speaker with a frequency range of 68Hz to 17kHz. Control 12C/T is available in either black or white finish with matching grille and vented, painted baffle. The pre-attached, 138mm depth, ‘blind-mount’ back can allows for quick integration within the ceilings of up to 35mm in thickness and 170mm cutout.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Discontinued
This speaker has many of the features of the Control 12C/T, however it is EN54-24 compliant, preventing any water ingress to a minimum of IP-21, per IEC529/60529. This compliance and other features including a high-temperature ceramic input connector make it a viable option for voice alarm systems.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Discontinued
This 2-way, 4-inch coaxial ceiling loudspeaker has the same mounting method as the Control 12C/T. The 100mm/19mm coaxial driver allows a frequency range of 74Hz to 20kHz, and it can be used within a low impedance, 70V or 100V line system.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Control 14C-VA – 4-inch coaxial, EN54-24 compliant
Discontinued
This ceiling speaker shares the features of the Control 14C/T, however like the Control 12C-VA the Control 14C-VA is EN54-24 certified.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Discontinued
This 2-way, 6.5-inch coaxial ceiling loudspeaker has the same mounting method as the Control 12C/T. The 165mm/19mm coaxial driver allows a frequency range of 62Hz to 20kHz, and it can be used within a low impedance, 70V or 100V line system.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Control 16C-VA – 6.5-inch coaxial, EN54-24 compliant
Discontinued
This ceiling speaker shares the features of the Control 16C/T, however like the Control 12C-VA the Control 16C-VA is EN54-24 certified.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Discontinued
This 2-way, 8-inch coaxial ceiling loudspeaker has the same mounting method as the Control 12C/T. The 200mm/25mm coaxial driver allows a frequency range of 58Hz to 20kHz, and it can be used within a low impedance, 70V or 100V line system.
Included accessories (per speaker): 2x Tile rail supports, 1x C-ring support, cutout template, paint shield, and grille.
Technical specifications
Notes: *1 Program power, continuous
Ordering note
Most, but not all items in this range are packed and priced in pairs. Ensure you order correctly, eg. 1 ×76-510 orders 1 pair Control 12C/T loudspeakers. Items ordered incorrectly will be subject to a returns handling charge.
