SOWTER ST3678F TRANSFORMER Analogue audio, leads, microphone input

Stock code
23-179
Brand
Sowter
Model number
  • ST3678F
SOWTER ST3678F TRANSFORMER Analogue audio, leads, microphone input

Image may be provided for illustrative purposes only, please refer to the product description.

SOWTER ST3678F TRANSFORMER Analogue audio, leads, microphone inputSOWTER ST3678F TRANSFORMER Analogue audio, leads, microphone inputSOWTER ST3678F TRANSFORMER Analogue audio, leads, microphone input

Order

VAT / Delivery
$118.09
each (ex. VAT)
10+ $114.55
50+ $112.19
100+ $109.82
Ordered on demand, available in 3‑4 weeks. Need it sooner? Call us
RoHS Compliant

SOWTER AUDIO TRANSFORMERS

A range of high performance audio transformers with pins for PCB mounting or with colour coded flying leads. Mumetal cores are used for minimal distortion and high bandwidth (except type 4652). All types (except miniature and 4652 types) are housed in a heavy gauge cylindrical Mumetal can for hum isolation. Flying lead types have tapped fixing holes with screws supplied. Line bridging, input/output and high performance microphone types have multiple internal electrostatic shields to ensure optimum balance and noise rejection. Descriptive data sheets with performance graphs for any type number are available on request.

Note: Suffix of C denotes PCB mounting variety. Suffix of F denotes flying leads.
